Preis ab

$ 3.999

Leistung

11.0 kW (15.0 hp) at 9500 rpm

Max. Drehmoment

12,1 N·m/7000 r/min

Trockengewicht (KG)

142

Technische Daten

  • TYP

    1-Zylinder/4-Takt/4-Ventil

    Hubraum (cc)

    125

    Bohrung x Hub (mm)

    ø54×54,5

    Leistung

    11.0 kW (15.0 hp) at 9500 rpm

    Maximales Drehmoment

    12,1 N·m/7000 r/min

    Kompressionsverhältnis

    12. 0:1

    Kraftstoffsystem

    EFI

    Ventiltrieb

    SOHC

    Anlasser

    Elektrisch

    Schmiersystem

    Zwangsschmierung mit Nasssumpf

    Kühlsystem

    Flüssigkeitsgekühlt

    Zündung

    BOSCH MOTRONIC MES 8.0

  • Getriebe

    6-Gang

    Endantrieb

    Kette

    Kupplungstyp

    Nasse Kupplung

  • Rahmen

    Gestell aus Stahl in Stahlrohren

    Vorderrad

    Aluminiumlegierung

    Vordere Federung

    41 mm upside-down forks full adjustable in spring preload and hydraulic brake rebound and compression

    Vorderer Reifen

    100/80—17 M/C

    Vorderradbremse

    Single disks with 4 pistons calliper with and ABS

    Durchmesser der Vorderradbremse (mm)

    280

    Hinterrad

    Aluminiumlegierung

    Hintere Federung

    Rear swing arm in steel, shock absorber with progressive link, adjustable in spring preload and hydraulic brake rebound

    Hinterer Reifen

    130/70-17 M/C

    Hinterradbremse

    Single disc with floating calliper single piston

    Durchmesser der Hinterradbremse (mm)

    240

  • Trockengewicht (kg)

    142

    Sitzhöhe (mm)

    820

    Gesamtlänge (mm)

    2010

    Gesamtbreite (mm)

    910

    Gesamthöhe (mm)

    1135

    Bodenfreiheit (mm)

    198

    Radstand (mm)

    1390

    Tankinhalt (L)

    12
