Cena od

$ 11,290

Moc

9kW at 8000 r/min

Maks. Moment obrotowy

11N·m/6500 r/min

Waga sucha (KG)

171

Specyfikacja techniczna

  • TYPE

    1-cylinder/4-stroke/2-valve

    Displacement (cc)

    148

    Bore x Stroke (mm)

    ø57×58

    Power

    9kW at 8000 r/min

    Max torque

    11N·m/6500 r/min

    Compression ratio

    9.27:1

    Fuel system

    Carburetor

    Valve train

    SOHC

    Starter

    Electric & kick

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Air-cooled

    Ignition

    C.D.I.

  • Gearbox

    5-speed

    Final drive

    V-belt

    Clutch type

    Wet multi-plate

  • Frame

    Diamond

    Front wheel

    Aluminum alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    110

    Front tyre

    90/90-17

    Front brake

    Disc

    Front brake diameter (mm)

    240

    Rear wheel

    Aluminum alloy

    Rear suspension

    Mono-shock-absorber, preload adjustable

    Rear suspension travel (mm)

    30

    Rear tyre

    120/80-17

    Rear brake

    Drum

    Rear brake diameter (mm)

    130

  • Curb weight (kg)

    171

    Seat height (mm)

    760

    Overall length (mm)

    2090

    Overall width (mm)

    790

    Overall height (mm)

    1090

    Ground clearance (mm)

    180

    Wheelbase (mm)

    1350

    Fuel capacity (L)

    16

    Top speed (km/h)

    100

    Max load (kg)

    171

    Battery

    12V7Ah
