Preis ab (UVP)

$ 22,990

Leistung

19kW at 9250 r/min

Max. Drehmoment

21.2N·m/8000 r/min

Leergewicht (KG)

155

Technische Daten

  • TYPE

    1-cylinder/4-stroke/4-valve

    Displacement (cc)

    249

    Bore x Stroke (mm)

    ø72×61.2

    Power

    19kW at 9250 r/min

    Max torque

    21.2N·m/8000 r/min

    Compression ratio

    11.2:1

    Fuel system

    EFI

    Valve train

    DOHC

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Liquid-cooled

    Ignition

    T.C.I.

  • Gearbox

    6-speed

    Final drive

    Chain

    Clutch type

    Wet multi-plate

  • Frame

    Steel trellis frame

    Front wheel

    Aluminum alloy

    Front suspension travel (mm)

    120

    Front tyre

    100/80-17

    Front brake

    Disc

    Front brake diameter (mm)

    260

    Rear wheel

    Aluminum alloy

    Rear suspension

    Mono-shock-absorber

    Rear suspension travel (mm)

    45

    Rear tyre

    130/70-17

    Rear brake

    Disc

    Rear brake diameter (mm)

    240

  • Curb weight (kg)

    155

    Seat height (mm)

    780

    Overall length (mm)

    2050

    Overall width (mm)

    810

    Overall height (mm)

    1065

    Ground clearance (mm)

    170

    Wheelbase (mm)

    1365

    Fuel capacity (L)

    13.5

    Top speed (km/h)

    129

    Max load (kg)

    185

    Battery

    12V8Ah
