Cena od

$ 4.199

Moč

11.0 kW (15.0 hp) at 9500 rpm

Maksimalni navor

12,1 N·m/7000 r/min

Teža

N/A

Tehnične specifikacije

  • TYPE

    1-cylinder/4-stroke/4-valve

    Displacement (cc)

    125

    Bore x Stroke (mm)

    ø54×54.5

    Power

    11.0 kW (15.0 hp) at 9500 rpm

    Max torque

    12,1 N·m/7000 r/min

    Compression ratio

    12.0:1

    Fuel system

    EFI

    Starter

    Electric

    Lubrication system

    Forced wet sump

    Cooling system

    Liquid-cooled

    Ignition

    BOSCH MOTRONIC MSE 8.0

  • Gearbox

    6-speed

    Final drive

    Chain

    Clutch type

    Wet clutch

  • Frame

    Steel trestle in steel tubes

    Front suspension

    41 mm upside-down forks full adjustable in spring preload and hydraulic brake rebound and compression

    Front tyre

    90/90 - 19 M/C

    Front brake

    Single floating disks with 4 pistons calliper with and ABS

    Front brake diameter (mm)

    280

    Rear suspension

    Rear swing arm in steel, shock absorber with progressive link, adjustable in spring preload and hydraulic brake rebound

    Rear tyre

    120/90 - 17 M/C

    Rear brake

    Single disc with floating calliper single piston

    Rear brake diameter (mm)

    240

  • Seat height (mm)

    860

    Overall length (mm)

    2090

    Overall width (mm)

    910

    Overall height (mm)

    1210

    Ground clearance (mm)

    233

    Wheelbase (mm)

    1430

    Fuel capacity (L)

    12
