Prezzo (f.c.)

N/A

Potenza Massima

9.5kW at 7500 r/min

COPPIA MASSIMA

13.9N·m/6000 r/min

Peso a secco (KG)

N/A

Specifiche tecniche

  • TYPE

    1-cylinder/4-stroke/2-valve

    Displacement (cc)

    197

    Bore x Stroke (mm)

    ø63.5×62.2

    Power

    9.5kW at 7500 r/min

    Max torque

    13.9N·m/6000 r/min

    Compression ratio

    8.3:1

    Fuel system

    EFI

    Valve train

    OHV

    Starter

    Electric & kick

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Air-cooled

    Ignition

    C.D.I.

  • Gearbox

    5-speed

    Final drive

    Chain

    Clutch type

    Wet multi-plate

  • Frame

    Double-cradle

    Front wheel

    Aluminum alloy

    Front suspension

    Telescopic forks

    Front suspension travel (mm)

    120

    Front tyre

    90/90-17

    Front brake

    Disc, 2-piston caliper

    Front brake diameter (mm)

    280

    Rear wheel

    Aluminum alloy

    Rear suspension

    Dual shock-absorber, preload adjustable

    Rear suspension travel (mm)

    53

    Rear tyre

    130/90-15

    Rear brake

    Disc, 2-piston caliper

    Rear brake diameter (mm)

    240

  • Seat height (mm)

    715

    Overall length (mm)

    2140

    Overall width (mm)

    800

    Overall height (mm)

    1050

    Ground clearance (mm)

    150

    Wheelbase (mm)

    1440

    Fuel capacity (L)

    11.8

    Top speed (km/h)

    100

    Max load (kg)

    185

    Battery

    12V6Ah
